Show HN: Movie Iris

Movie Iris

Matrix (1999)

Movie: Up (2009)

Movie: Hero (2002)

Introduction

The Movie Iris project was something that I started working on during quarantine. I saw some cool visualizations on Reddit’s r/dataisbeautiful and was inspired to start working on the project. Some other users had already done something like this – and I wanted to try my hand at is as well. This repo is my take on turning movies into still art. Effectively taking raw movie frames, compressing them to their core colors, and visualizing the color schemes of a movie. I wanted to see how movies evolve, as well as how directors intended for different colors to be prevalent across different scenes. I wanted to make something artistic and visual, and I figured this would be a great opportunity to learn how to do some image processing, while making something that I’ll actually get to enjoy as well as share with friends and family!

P.S. Feel free to message me if you want me to do this to a video of yours!

Overview

This repo takes in a video (can be .mp4, .avi, .mkv), and visualizes the color themes present in the video as a barcode and as a circle. There are 2 outputs to this script: barcode.png and iris.png. The outputs and all of the actual frames in this script are .png as it is as lossless format. Important to note – this is not just for movies – any video can be used (TV show episode, first bike ride, travel video, etc.)

Dependencies

This project was written in Python, and uses 2 main libraries:

CV2
PIL

Process

video_to_barcode.ipynb

This file takes 4 inputs:

Height of the final barcode
The name of the video
The vidcap (filepath of the video)
The frame count that we want to capture

The script creates a local folder to store all of the files that are going to be created

We divide the total amount of frames in the video by the desired frame_count, in order to figure out how many frames to skip for each frame we capture. We then capture the frames, skip by the correct amount, and capture again. We then save the newly created frames locally to the new folder we created. This interval allows us to capture the essence of the video.

We then increase the contrast slightly in each frame, in order to make more vibrant colors.

We take these new contrasted_frames and resize the images 3 times, finally reaching our desired size, which is 1 pixel wide x 1000 pixels high image.

We then take each frame, and effectively merge them together, creating a 6400 pixel wide x 1000 pixel high barcode, where each pixel is 1 distinct frame from the video.

We then run the linear_to_circular.ipynb file.

linear_to_circular.ipynb

This file also takes 4 inputs:

The name of the video
Current working directory
The final images working directory
The name of the final barcode we created in the previous file.

However, we don’t need to pass these in, as they are imported from the previous file, and we can just continue with those variables.

The first thing we do is read in the barcode image that was made in video_to_barcode.ipynb

We then create a white stripe along the bottom of the image. This is so that when we transform the image to polar coordinates, the bottom of the image becomes the center, and we can get a nice white circle in the middle, to create that iris visualization.

The next thing we do is convert the barcode image to polar coordinates. There are multiple input arguments for the warpPolar function:

src
dsize
center
maxRadius
flags

src: is effectively the source image we want to convert to polar coordinates – this should stay the same.

dsize: is how large we want the output image to be — these measurements we’re a lot of trial and error on my part – you can tweak these as you see fit.

center: is where we want the center of the image to be, relative to the dsize. This should not be changed, as it will dynamically update with the dsize_args parameter.

maxRadius: is how large we want the circle to be — this was also a lot of trial and error to get a good fit for the image – this can be tweaked as well.

flags: is how the warpPolar function knows how to modify the src. This should not be touched.

Output the image.
